L712/L710/L708/L706/L704/L703

TEL

+8618818860685

Online Consulting

Product description

PRODUCT FEATURES:

◆Two-channel entertainment-grade professional amplifier, efficient TD, H, AB class, pure sound quality with delicate and sweet performance;

◆SMT surface mount technology, high integration, and more stable product performance;

◆Efficient silent fan cooling system, the machine is extremely quiet, and the temperature inside and on the surface of the chassis is low;

◆Super perfect protection system, including high-frequency protection, overload/overcurrent protection, over-temperature protection, output short-circuit protection, DC protection, distortion limit protection, etc. To ensure stable operation in various harsh environments;

◆Powered by toroidal transformer, the low frequency is more powerful;

◆Suitable for tailor-made KTV rooms, language amplification, and design of medium and small-sized performances.

TECHNICAL PARAMETERS:

FP Series	L712	L710	L708	L706	L704	L703
Rated Power 8Ω Stereo	1200WX2	1000WX2	800WX2	600WX2	400WX2	300WX2
Rated Power 4Ω Stereo	2200WX2	1800WX2	1500WX2	800WX2	650WX2	550WX2
Frequency response	20Hz-20KHz	20Hz-20KHz	20Hz-20KHz	20Hz-20KHz	20Hz-20KHz	20Hz-20KHz
THD	＜0.05%	＜0.05%	＜0.05%	＜0.05%	≤0.08%	≤0.08%
Signal to noise ratio	＞98dB	＞105dB	＞93dB	＞93dB	≥103dB	≥103dB
Coeffcient of damping	＞1000	＞1000	＞600	＞600	≥350	≥350
Conversion rate	＞20V/us	＞20V/us	＞20V/us	＞20V/us	＞20V/us	＞20V/us
Input resistance	10KΩ/20KΩ	10KΩ/20KΩ	10KΩ	10KΩ/20KΩ	10KΩ/20KΩ	10KΩ/20KΩ
Input Sensitivity	0.775V/1.0V/1.44V	1.0V	1.0V	1.0V	0.775V/1.0V/1.44V	0.775V/1.0V/1.44V
Resolution	＞70dB	＞70dB	＞70dB	＞70dB	≥65dB	≥65dB
net weight	20.5KG	17KG	15.3KG	9KG	12.2KG	11KG
Product Size	483x468x88	483x385x88	483x385x88	483x385x88	483x360x88	483x360x88
